TP-LINK TL-P150-48 industrial grade 150W chassis type industrial power supply

Brand: TP-LINK

Model: TL-P150-48-Industrial-Grade

Weight: 416g

Dimensions: 159mm x 97mm x 30mm

Stable output 48V voltage, maximum output power 150W, support dual output -20°C ~ 75°C Watery Work (Specific Reference Manual) Wide voltage design, adapt to global market voltages Selected high-standard long life capacitance Support short-circuit protection, open loop protection, overload protection, over temperature protection By 100% full load aging test The output voltage

48VDC

Output current

3.3A (specific reference load curve)

rated power

150W (specific reference load curve)

Corrugation and noise

200mVp-p

Start time when full load

Rising time when full load

<25ms

Keep time when full load

>10ms

Input voltage

100~240VAC

Maximum

Product Features

Stable output 48V voltage, maximum output power 150W, support dual output
-20°C ~ 75°C Watery Work (Specific Reference Manual)
Wide voltage design, adapt to global market voltages
Selected high-standard long life capacitance
Support short-circuit protection, open loop protection, overload protection, over temperature protection
By 100% full load aging test

Technical Specifications

Property Description	Property Value
The output voltage	48VDC
Output current	3.3A (specific reference load curve)
rated power	150W (specific reference load curve)
Corrugation and noise	200mVp-p
Start time when full load	<3s
Rising time when full load	<25ms
Keep time when full load	>10ms
Input voltage	100~240VAC
Maximum input current	3.5A
Typical efficiency	89.8%@115VAC 91.5%@230VAC
Inrush current	<90A@115VAC;<120A@230VAC
protection	short circuit protection open loop protection overload protection Over temperature protection
surroundings	Operating temperature: -20°C ~ 75°C (Specific Reference Manual) 10% ~ 90% RH does not condense storage temperature: -40°C ~ 85°C Storage humidity: 5% ~ 90% RH does not condense
size	159mmx97mmx30mm(without buckle) 159mmx97mmx39mm(with buckle)
weight	416g
