TP-LINK TL-SF1010D 10-port 100M unmanaged switch iron shell layer 2
10 10/100M self-adaptive RJ45 ports to meet the networking needs of small security monitoring environments Support port auto flip (Auto MDI / MDIX) function Support MAC address self-learning; support full-duplex working mode Plug and play, no management required Desktop housing with wall mounting holes for flexible deployment TL-SF1010D is a 10-port 100M Ethernet switch product developed by TP-LINK Technology Co., Ltd. for small security monitoring environment. It provides 8 10/100M ordinary ports and 2 10/100M uplink ports. Only one switch can Meet the needs of 8 or 4 security monitoring networks. 10 100M ports, suitable for small security monitoring network Provide 8 10/100M ordinary ports and 2 10/100M uplink ports; Only one switch can meet the networking requirements of 8-way or 4-way
Product Features
TL-SF1010D is a 10-port 100M Ethernet switch product developed by TP-LINK Technology Co., Ltd. for small security monitoring environment. It provides 8 10/100M ordinary ports and 2 10/100M uplink ports. Only one switch can Meet the needs of 8 or 4 security monitoring networks. 10 100M ports, suitable for small security monitoring networkProvide 8 10/100M ordinary ports and 2 10/100M uplink ports; Only one switch can meet the networking requirements of 8-way or 4-way security monitoring network; Each port supports MDI / MDIX automatic rollover and duplex / rate auto-negotiation; Supports IEEE 802.3x full-duplex flow control and Backpressure half-duplex flow control. Plug and play, simple to use, flexible deploymentPlug and play, no management required; Dynamic LED indicator provides simple working status prompts and troubleshooting methods; Desktop-type housing with wall-mounting holes can be flexibly deployed as required. |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Network Standard | IEEE802.3、IEEE802.3u、IEEE802.3x |
| Network media | 10BASE-T: Category 3, 4, 5 unShielded twisted pair (≤100 meters) <100BASE-TX: Category 5 and above unShielded twisted pair (≤100 meters) |
| port | 10 10/100M adaptive RJ45 ports |
| Indicator light | Per port: Link/Act Per device: PWR |
| performance | Store and forward support 2K MAC address table depth |
| Overall dimensions (L * W * H) | 158x100x25(mm) |
| Input voltage | External power adapter: 5VDC / 0.6A |
| Use environment | Operating temperature: 0°C~40°C; Storage temperature: -40°C~70°C Operating humidity: 10%~90% RH non-condensing; Storage humidity: 5%~90% RH non-condensing |
| basic skills | Wire-speed forwarding MAC automatic learning and aging IEEE802.3X full-duplex flow control and Backpressure half-duplex flow control |
| Forwarding rate | 10BASE-T: 14880pps 100BASE-TX: 148800pps/port |
