TP-LINK TL-SG2818F Industrial Grade Web Managed Industrial Ethernet Switch

Brand: TP-LINK

Model: TL-SG2818F-Industrial-Grade

Dimensions: 137mm x 128mm x 85.60mm

Provide 8 10/100/1000M auto-adaptive RJ45 ports and 10 Gigabit SFP ports Industrial grade working temperature: -40°C ~ 65°C Wide voltage input: 9.6V~60VDC Multiple installation methods: rail installation + wall installation IP30 protection: reduce the impact of dust Provide WEB management, broadcast storm protection and port interruption alarm switch, adapt to various complex network environments Support cloud management functions, realize remote viewing device status, exception alarm, remote discharge Three-way power input, redundant backup, greatly improve the product power supply reliability EMS high protection level, without fear of various harsh environments *Industrial switches are not equipped with power supply at the factory, please purchase separately if you need to use power

Product Features

Provide 8 10/100/1000M auto-adaptive RJ45 ports and 10 Gigabit SFP ports
Industrial grade working temperature: -40°C ~ 65°C
Wide voltage input: 9.6V~60VDC
Multiple installation methods: rail installation + wall installation
IP30 protection: reduce the impact of dust
Provide WEB management, broadcast storm protection and port interruption alarm switch, adapt to various complex network environments
Support cloud management functions, realize remote viewing device status, exception alarm, remote discharge
Three-way power input, redundant backup, greatly improve the product power supply reliability
EMS high protection level, without fear of various harsh environments
*Industrial switches are not equipped with power supply at the factory, please purchase separately if you need to use power supply
Recommended to buy our industrial grade power supply: TL-P60D-48 industrial grade

Technical Specifications

Property Description	Property Value
Protocol standard	IEEE 802.3,802.3i,802.3u,802.3x,802.3ab,802.3z
Port shape	8 gigabit RJ45 ports 10 gigabit SFP ports
Indicator light	18 Status Indicators Link/ACT PWR1, PWR2, PWR3
power input	DC input voltage 12/24/48 VDC (9.6 ~ 60 VDC) input current 1A (@ 24VDC) support reverse protection
Switch performance	support storage forwarding MAC address table depth 8K
DIP	Support broadcast storm protection Support Web Management / Cloud Management
structure	IP30 protection rating product size 137mm * 128mm * 85.6mm guide rail / wall installation
temperature	operating temperature -40°C - 65°C storage temperature -40°C - 85°C
humidity	Working humidity 10% RH - 90% RH, no condensation storage humidity 5% RH - 90% RH, no condensation
Certification Standards_EMS	IEC/EN 61000-4-2,Level 4 IEC/EN 61000-4-3,Level 4 IEC/EN 61000-4-4,Level 4 IEC/EN 61000-4-5,Level 3 IEC/EN 61000-4-6,Level 3 IEC/EN 61000-4-8,Level 5 IEC/EN 61000-4-9,Level 5 IEC/EN 61000-4-10,Level 5
Port configuration	Support Port On / Li> Support Port Flow Control On / Off Support Port Rate / Dual Work
Layer 2 switching	support port address dynamic learning support port gathering
Port mirroring	Support traffic statistics Support local / entry monitoring support cable detection, loopback detection
Packaging accessories	Wallpaper Warranty Card User Manual
