TP-LINK TG-3269E Gigabit Wired PCI-E NIC
Support 10/100/1000Mbps auto-negotiation, full duplex/half duplex auto negotiation New generation PCI Express (PCI-E) bus interface, more efficient data transmission Support Windows 7/8/10, Windows Server, Linux and other mainstream operating systems Support Wake On LAN function In line with IEEE 802.3i, IEEE 802.3u, IEEE 802.3AB, IEEE 802.3x Gigabit rate TG-3269E supports 10/100/1000M rate, all-duplex half-duplex adaptive, is ideal for Gigabit networks to desktop, enhance network performance. PCI-E interface TG-3269E supports a new generation of PCI Express (PCIe) bus interface, data transmission is more efficient, and the space is smaller. Good compatibility TG-3269E is compatible with common operating systems, including 32/64-bit systems of Windows 7, 8, 8.1, 10, Windows Server 2008 R2
Product Features
Gigabit rateTG-3269E supports 10/100/1000M rate, all-duplex half-duplex adaptive, is ideal for Gigabit networks to desktop, enhance network performance. PCI-E interfaceTG-3269E supports a new generation of PCI Express (PCIe) bus interface, data transmission is more efficient, and the space is smaller.Good compatibilityTG-3269E is compatible with common operating systems, including 32/64-bit systems of Windows 7, 8, 8.1, 10, Windows Server 2008 R2, 2012, 2012 R2, 2016, Linux system, and provides corresponding drivers.Easy to useThe TG-3269E is easy to use, simply insert it to the corresponding PCIE slot, and install the appropriate driver to use. Port supports automatic flipping, which can be directly connected to other network devices, making it easy to connect into the target network. |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Protocol standard | IEEE802.1P, IEEE802.1Q, IEEE802.3 10Base-T, IEEE802.3u 100Base-TX, IEEE802.3ab 1000Base-T compatible with PCI -E 1.1 bus standard |
| interface | 1 10/100/1000M adaptive RJ45 port (supports auto flip) |
| LED | 10M indicator, 100M indicator, 1000M indicator |
| Physical medium | 10Base-T: Category 3 or above Shielded/unShielded twisted pair; 100Base-TX: Category 5 Shielded/unShielded twisted pair 1000Base-T: Category 5 Shielded/unShielded twisted pair (Super Category 5 is recommended line) |
| Packaging accessories | Installation Guide CD |
| Use environment | Operating temperature: 0°C to 40°C; Storage temperature: -40°C to 70°C; Operating humidity: 10% to 90%RH non-condensing; Storage humidity: 5% to 90%RH non-condensing |
