TP-LINK TL-CPE1300D Industrial Grade Industrial Grade Dual Band Wireless Client

Brand: TP-LINK
Model: TL-CPE1300D-industrial-grade
Dimensions: 116mm x 76mm x 26mm

Adapt to the harsh industrial working environment at -40℃~+75℃ IEC/EN 61000-4 high standard industrial grade protection design, adapt to harsh environment Simultaneous connection of 2.4GHz and 5GHz dual-band radio frequency to improve communication reliability Advanced 11AC technology, wireless rate up to 1267Mbps Independent power amplifier circuit to increase the transmission power Support the device to work as Client, Client-Router mode, the body is small and compact, suitable for installation on the mobile terminal to provide wireless communication Enhanced roaming technology, Client/Client-Router mode devices can quickly roam to APs with better signals Wireless redundancy technology, device communication is not interrupted under interference Compact steel shell body, exquisite and

Product Features


  • Adapt to the harsh industrial working environment at -40℃~+75℃
  • IEC/EN 61000-4 high standard industrial grade protection design, adapt to harsh environment
  • Simultaneous connection of 2.4GHz and 5GHz dual-band radio frequency to improve communication reliability
  • Advanced 11AC technology, wireless rate up to 1267Mbps
  • Independent power amplifier circuit to increase the transmission power
  • Support the device to work as Client, Client-Router mode, the body is small and compact, suitable for installation on the mobile terminal to provide wireless communication
  • Enhanced roaming technology, Client/Client-Router mode devices can quickly roam to APs with better signals
  • Wireless redundancy technology, device communication is not interrupted under interference
  • Compact steel shell body, exquisite and beautiful, durable, efficient heat dissipation
  • Standard DIN rail/wall-mounted installation, easy maintenance
  • Support centralized management of TP-LINK commercial network cloud platform

Technical Specifications

Property DescriptionProperty Value
Product model
  • TL-CPE1300D Industrial Grade
Installation method
  • standard rail / wall installation
  • Distribution DIN rail buckle with wall pendant
size
  • 116 x 76 x 26 mm (excluding antenna part)
  • steel housing
wireless
  • 2.4GHz band: 400Mbps
  • 5GHz frequency band: 867Mbps
port
  • 2 10/100Mbps RJ45 ports
  • 1 RS-232/422/485 DB9 serial port
  • 1 pair of DC terminal power supply interface (V+, V- )
  • 2 RP-SMA antenna interfaces
  • 1 grounding interface
antenna
  • external two double frequency detachable 3DBI full-to-Direction antenna, factory delivery
Antenna coverage angle
  • 360°
Indicator light
  • 1 SYS system indicator
  • 2 LAN NED indicators
  • 1 WLAN Wireless status indicator
  • 1 serial Serial port indicator
  • All types of lights are displayed on both ends of the product
Button
  • 1 reset button
power supply
  • 9-48 VDC redundant DC power supply
  • support reverse protection
Maximum machine power consumption
  • 13.4W
Management method
  • web page Self-management
  • TP-LINK Commercial Network Cloud Platform Concentration Management
Use environment
  • operating temperature: -40°C ~ 75°C
  • Working humidity: 10% ~ 90% RH does not condense
  • storage temperature: -40°C ~ 85°C < / li>
  • storage humidity: 5% ~ 90% RH does not condense
wireless function
  • Working mode: Client, Client-Router (access to wireless network)
  • Quick Setup Wizard: Support
  • Enhanced Roaming: Support
  • Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK
  • Transmission power setting: support 1dBm linear adjustment
  • Serial port function: support TCP Server, TCP Client, UDP mode< /li>
  • Hotspot function: support
  • Wireless redundancy: support
System Management
  • device management: full Chinese Web Management
  • restore factory setting: Support
  • backup configuration: support
  • Import configuration: Support
  • software upgrade: support
  • ping watchdog: Support
Client-Router network
  • DHCP Server: Supported
  • Static Address Assignment: Supported
  • NAT: Supported
  • Static Routing: Supported
  • ul>
