TP-LINK TL-CPE201 2.4GHz 300M Outdoor Wireless CPE

Brand: TP-LINK

Model: TL-CPE201

Dimensions: 176mm x 75mm x 44mm

Professional outdoor shell design, adapt to various harsh environments 300M wireless, built-in high-gain dual-polarized antenna, providing high-performance wireless WEB management system provides abundant software functions Support point-to-point, point-to-multipoint multiple connection methods, the use scenarios are more abundant Support button matching, quickly complete a pair of multi-network pairs Support TP-LINK bridge centralized management software for unified management of all devices Support 24V Passive PoE and DC power supply, compatible with 12V DC power supply, adapt to a variety of power supply scenes Wireless standard

IEEE 802.11b/g/n

Whether it supports wide voltage power supply

The bridge supports wide voltage power supply: 9V-25V

Power

Product Features

Professional outdoor shell design, adapt to various harsh environments
300M wireless, built-in high-gain dual-polarized antenna, providing high-performance wireless
WEB management system provides abundant software functions
Support point-to-point, point-to-multipoint multiple connection methods, the use scenarios are more abundant
Support button matching, quickly complete a pair of multi-network pairs
Support TP-LINK bridge centralized management software for unified management of all devices
Support 24V Passive PoE and DC power supply, compatible with 12V DC power supply, adapt to a variety of power supply scenes

Technical Specifications

Property Description	Property Value
Wireless standard	IEEE 802.11b/g/n
Whether it supports wide voltage power supply	The bridge supports wide voltage power supply: 9V-25V
Power Adapter	24V/0.25A
Maximum power of the whole machine	2.787W (without power adapter) 3.52W (with power adapter)
Wireless working mode	AP、Client
Network settings	LAN port connection: Static IP
wireless setting	802.11b/g/n mode automatic channel selection Transmission power adjustment WDS wireless security : WPA / WPA2, WPA-PSK / WPA2-PSK (AES / TKIP) Encryption, 64/128/152 Bit WEP Encryption SSID Broadcast / Hide Multi SSID, SSID TAG VLAN Map (AP mode only) Distance setting wireless MAC address filter Advanced setting: Beacon time slot, RTS threshold, slice threshold, DTIM Interval, AP Isolation, Short Gi, WMM
Management and maintenance	Centralized management software centralized management software HTTP / HTTPS Web Management system log ping watchdog < / li> TP-LINK Commercial Network Cloud Platform Management
System Tools	system status: signal strength, noise intensity, transmission CCQ, CPU usage, memory occupancy status monitoring: throughput / wireless client / interface / arp rate test ping
System Optimization	IGMP snooping optimization, multicast agent hardware watchdog
Antenna coverage angle	Level Direction: 65° vertical Direction: 35°
Product Size	1767544mm
