TP-LINK TL-NAC300-NMS TP-LINK Multi-Service Wireless Controller

Brand: TP-LINK

Model: TL-NAC300-NMS

Dimensions: 180mm x 294mm x 44mm

Integrated wireless controller and network centralized control function Supports the wireless controller function, which can uniformly manage the APs that TP-LINK works in the thin AP (FIT AP) mode. Support AP automatic discovery, AP status view, AP unified configuration, AP MAC address filtering, AP software unified upgrade, AC bypass networking, no need to change the existing network structure, easy deployment, unified wireless network configuration, support SSID and Tag VLAN mapping , AP LED lights on and off. Support network centralized control function, can manage TP-LINK routing, switching, AP and other network equipment in a unified way. It supports the whole network management and operation and maintenance functions such as intelligent deployment, network topology, network

Product Features

Integrated wireless controller and network centralized control function
Supports the wireless controller function, which can uniformly manage the APs that TP-LINK works in the thin AP (FIT AP) mode. Support AP automatic discovery, AP status view, AP unified configuration, AP MAC address filtering, AP software unified upgrade, AC bypass networking, no need to change the existing network structure, easy deployment, unified wireless network configuration, support SSID and Tag VLAN mapping , AP LED lights on and off.
Support network centralized control function, can manage TP-LINK routing, switching, AP and other network equipment in a unified way. It supports the whole network management and operation and maintenance functions such as intelligent deployment, network topology, network inspection, automatic discovery of network devices, wireless intelligent roaming, and connectivity diagnosis, which simplifies the process and operation of local deployment for users
Support TP-LINK commercial network cloud platform/Shangyun APP remote viewing/management* (subsequent addition)

Technical Specifications

Property Description	Property Value
port	2 10/100/1000M RJ45 ports
processor	64-bit MIPS network dedicated processor, single core frequency 800MHz
RAM	DDRII 256MB
FLASH	128MB
Indicator light	Each port: LINK / ACT, 1000M / 100M Each device: PWR, SYS
Dimensions	294(w)x180(D)x44(H) mm
Input power	100~240V AC,50/60Hz
Cooling method	Natural heat dissipation
Use environment	operating temperature: 0°C ~ 40°C Working humidity: 10% ~ 90% RH does not condense storage temperature: -40°C ~ 70°C Storage humidity: 5% ~ 90% RH does not condense
Maximum number of manageable network devices	300 sets
Maximum number of SSIDs supported	300 (support Chinese SSID)
Network Overview	Number of network devices such as routing, firewall, switching, etc. Network topology
wireless function	Wireless network unified configuration DHCP server Layer 2 fast roaming automatic channel adjustment linear power adjustment WMM, Short Gi Prohibition of weak signal client access and kicking weak signal client
Wireless security	64/128/152 Bit WEP Encryption, WPA-PSK / WPA2-PSK (AES / TKTP), WPA / WPA2 Security Mechanism SSID Isolation, the internal isolation of the AP SSID and TAG VLAN mapping
Resource List	Automatic discovery of network devices Display the unified management and configuration of network devices Display the total number/offline number of network devices Network device modification groups Restart network devices Unify upgrade of network device software Online terminal statistics User list display/blocking < /ul>
AP management	AP automatically discovered AP unified configuration and management AP timing restart AP software automatically unified upgrade Load balancing based on access users Adaptive rate adjustment associated user limit AP LED light open and close AP Batch Editing AP Packet Management
verification method	MAC Authentication Portal Authentication: Local Portal, Remote Portal, CMCC Portal
Authentication server	local server, radius
system status	System Resource Status AP Run State Wireless Client Status Certified User Status
Management and maintenance	Configuration backup and import configuration Device restart and factory reset Software upgrade ping detection, tracert detection Time Settings Interface Configuration IP Address Assignment System Logs WEB Management
