TP-LINK TL-S5G-5KM monitoring Gigabit wireless network bridge single installed indoor and outdoor universal 5KM 867M
Professional outdoor shell design, adapt to various harsh environments 11AC wireless technology, 867Mbps wireless rate Full Gigabit port for better wireless performance Pure 5GHz frequency band, less interference, wireless transmission distance up to 5 kilometers Factory-free setting, default setting for bridge connection Support Passive PoE and DC power supply The wireless transmission power is linearly adjustable, adjust the transmission distance according to the demand, and avoid the same frequency interference Product model TL-S5G-5KM camera end TL-S5G-5KM video recorder end Installation method Pole mounting wireless Working frequency band: 5.15~5.25GHz, 5.735~5.835GHz Wireless rate: 867Mbps Wireless standard: IEEE 802.11a/n/ac Transmit power 20dBm antenna Built-in 13dBi
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Product model | TL-S5G-5KM camera end TL-S5G-5KM video recorder end |
| Installation method | Pole mounting |
| wireless | Working frequency band: 5.15~5.25GHz, 5.735~5.835GHz Wireless rate: 867Mbps Wireless standard: IEEE 802.11a/n/ac |
| Transmit power | 20dBm |
| antenna | Built-in 13dBi dual-polarized antenna |
| Maximum wireless transmission distance (no interference) | 5 KM |
| port | 1 10/100/1000Mbps RJ45 port (LAN0/POE) 1 10/100/1000Mbps RJ45 port (LAN1) 1 DC power jack port |
| Power supply | 12V / 1A Passive PoE power supply, power supply distance up to 55M |
| Indicator light | PWR, LAN0, LAN1, 4 signal strength indicators |
| Antenna coverage angle | Horizontal Direction: 45° Vertical Direction: 30° |
| Product Size | 224x79x60(mm) |
| Use environment | Operating temperature: -30°C~70°C Storage temperature: -40°C~70°C Operating humidity: 10%~90%RH non-condensing Storage humidity: 5%~90%RH non-condensing |
| Dust and water resistance | ASA engineering plastic case, IP55 dustproof and waterproof |
| Wireless working mode | Video recorder, camera |
| Network settings | LAN port connection: Static IP |
| wireless setting | 802.11a/n/ac mode automatic channel selection, transmission power adjustment, wireless security: WPA/WPA2, WPA-PSK/WPA2-PSK (AES/TKIP) encryption, 64/128/152-bit WEP encryption, SSID broadcast / no WDS channel bandwidth Select advanced settings: Beacon time slot, RTS threshold, fragmentation threshold, DTIM interval, AP isolation, Short GI, WMM |
| Management and maintenance | HTTP/HTTPS WEB Management System Log Ping Watchdog Time Setting |
| System Tools | System status: signal strength, noise strength, transmission CCQ, CPU occupancy rate Status monitoring: throughput/wireless client/ARP/DHCP server timing restart rate test Ping Traceroute |
| System Optimization | Hardware watchdog IGMP Snooping optimization |
