TP-LINK TL-SG1016DT T series 16-port full gigabit unmanaged switch iron shell layer 2 supports port isolation

Brand: TP-LINK
Model: TL-SG1016DT
Dimensions: 294mm x 180mm x 44mm

16 10/100/1000M adaptive RJ45 ports All ports have wire-speed forwarding capabilities Support port auto flip (Auto MDI / MDIX) function Provides three working modes of standard switching, VLAN isolation and network cloning, adapting to different network environments Support switch working mode by toggle switch Desktop-type housing, plug-and-play, rack-mountable Network Standard IEEE 802.3 、IEEE 802.3i、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3x port 16 10/100/1000Mbps RJ45 ports Indicator light Each port has 1 Link/Ack, Speed indicator light Each device has 1 Power indicator light performance Store and Forward Support 8K MAC address table depth Use environment Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90%RH, non-condensing Storage humidity: 5%~90%RH

Product Features


    • 16 10/100/1000M adaptive RJ45 ports
    • All ports have wire-speed forwarding capabilities
    • Support port auto flip (Auto MDI / MDIX) function
    • Provides three working modes of standard switching, VLAN isolation and network cloning, adapting to different network environments
    • Support switch working mode by toggle switch
    • Desktop-type housing, plug-and-play, rack-mountable

Technical Specifications

Property DescriptionProperty Value
Network StandardIEEE 802.3 、IEEE 802.3i、IEEE 802.3u、IEEE 802.3ab、IEEE 802.3x
port16 10/100/1000Mbps RJ45 ports
Indicator lightEach port has 1 Link/Ack, Speed indicator light Each device has 1 Power indicator light
performanceStore and Forward Support 8K MAC address table depth
Use environmentOperating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90%RH, non-condensing Storage humidity: 5%~90%RH, non-condensing
Input power100-240V~ 50/60Hz
Dimensions (L x W x H)294mm x 180mm x 44mm
Three mode switchingStandard switching, VLAN isolation, network cloning
