TP-LINK TL-WDR5620 Easy Exhibition Ac1200 Easy Exhibition Mesh Distributed Routing
Protocol standard IEEE802.11ac IEEE802.11n IEEE802.11g IEEE802.11b IEEE802.11a IEEE802.3 IEEE802.3u Wireless rate 2.4GHz frequency band: 300Mbps 5GHz frequency band: 867Mbps interface 4 10/100M adaptive WAN / LAN ports, support auto flip (Auto MDI / MDIX) Button Reset button Easy button LED System instructions antenna 4 external non-removable omniDirectional antennas size 230mm*144mm*37mm Equipment management Device information Real-time network speed Speed limit Disable device wireless function Wireless bridging Guest network Signal strength adjustment AP isolation other functions Parental Control Behavior Management Packaging accessories AC1200 dual-band wireless router TL-WDR5620 easy to show version power adapter user manual warranty card Use environment Operating temperature:
Technical Specifications
| Property Description | Property Value |
|---|---|
| Protocol standard | IEEE802.11ac IEEE802.11n IEEE802.11g IEEE802.11b IEEE802.11a IEEE802.3 IEEE802.3u |
| Wireless rate | 2.4GHz frequency band: 300Mbps 5GHz frequency band: 867Mbps |
| interface | 4 10/100M adaptive WAN / LAN ports, support auto flip (Auto MDI / MDIX) |
| Button | Reset button Easy button |
| LED | System instructions |
| antenna | 4 external non-removable omniDirectional antennas |
| size | 230mm*144mm*37mm |
| Equipment management | Device information Real-time network speed Speed limit Disable device |
| wireless function | Wireless bridging Guest network Signal strength adjustment AP isolation |
| other functions | Parental Control Behavior Management |
| Packaging accessories | AC1200 dual-band wireless router TL-WDR5620 easy to show version power adapter user manual warranty card |
| Use environment | Operating temperature: 0°C~40°C Storage temperature: -40°C~70°C Operating humidity: 10%~90% non-condensing Storage humidity: 5%~90% non-condensing |
