TP-LINK TL-CPE230 fixed end and car end set elevator wireless monitoring 2.4GHz 300M
11N wireless technology, 300Mbps wireless rate Easy transmission of 4K video in 100m elevator shaft environment Factory-free configuration, default setting for bridge connection Support Passive PoE power supply Flexible and simple installation, easy construction and deployment in elevator shaft The wireless transmission power is linearly adjustable, adjust the transmission distance according to the demand, and avoid the same frequency interference Independent hardware protection circuit can automatically recover abnormal AP Product model TL-CPE230 fixed end TL-CPE230 car end Installation method Ceiling / wall mounting size 190*170*30mm wireless Working frequency band: 2.4GHz-2.483GHz (China) Wireless speed: 300Mbps port 1 10/100M RJ45 port 1 DC power socket port Indicator light One system
Product Features |
Technical Specifications
| Property Description | Property Value |
|---|---|
| Product model | TL-CPE230 fixed end TL-CPE230 car end |
| Installation method | Ceiling / wall mounting |
| size | 190*170*30mm |
| wireless | Working frequency band: 2.4GHz-2.483GHz (China) Wireless speed: 300Mbps |
| port | 1 10/100M RJ45 port 1 DC power socket port |
| Indicator light | One system indicator |
| Button | 1 Reset button |
| power supply | 9VDC / 0.85A; Passive PoE power supply |
| management | Independent web page management |
| Use environment | Operating temperature: 0°C~40°C Operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C Storage humidity: 5%~90%RH non-condensing |
| wireless function | SSID broadcast: Support SSID quantity: 8 (support Chinese SSID) Wireless encryption: WPA, WPA2, WPA-PSK, WPA2-PSK Transmit power setting: support 1dBm linear adjustment WDS function: support QoS: WMM |
| System Management | Device management: All Chinese WEB management System log: support Restore factory settings: support Backup configuration: support Import configuration: support Software upgrade: support Ping watchdog: support |
