TP-LINK TL-TR901 4G to wired router three Netcom external LTE antenna outdoor waterproof and dustproof
The card is automatically connected to the network and can be monitored anytime and anywhere Support 4G full Netcom, up to 51.02Mbps uplink rate, up to 74.95Mbps downlink rate Support IP65 dustproof and waterproof, cope with various weather conditions Support 12VDC power output, power the camera at any time External LTE antenna, 4G signal is stronger Network Type 4G:LTE-TDD,LTE-FDD 3G:WCDMA 2G:GSM Frequency Range LTE-TDD BAND 34/38/39/40/41 LTE-FDD BAND 1/3/5/8 UTMS(WCDMA) BAND 1/5/8 GSM 900/1800MHz 4G/3G transmission rate LTE-FDD: uplink 51.02Mbps/downlink 74.95 Mbps LTE-TDD: uplink 30.61Mbps/downlink 65.38 Mbps Interface Type 1 DC12V power input interface 1 DC12V power output interface 1 10/100M adaptive RJ45 port 1 Nano-sim card slot power supply DC power supply 12V/4.8W Button Reset
Product Features
|
Technical Specifications
| Property Description | Property Value |
|---|---|
| Network Type | 4G:LTE-TDD,LTE-FDD 3G:WCDMA 2G:GSM |
| Frequency Range | LTE-TDD BAND 34/38/39/40/41 LTE-FDD BAND 1/3/5/8 UTMS(WCDMA) BAND 1/5/8 GSM 900/1800MHz |
| 4G/3G transmission rate | LTE-FDD: uplink 51.02Mbps/downlink 74.95 Mbps LTE-TDD: uplink 30.61Mbps/downlink 65.38 Mbps |
| Interface Type | 1 DC12V power input interface 1 DC12V power output interface 1 10/100M adaptive RJ45 port 1 Nano-sim card slot |
| power supply | DC power supply 12V/4.8W |
| Button | Reset button |
| antenna | External single LTE 4G antenna |
| Indicator light | 1 system indicator |
| size | 172mm*105mm*34mm |
| Installation method | Wall mount |
| Use environment | Operating temperature: -30°C~60°C Operating humidity: 10%~90%RH non-condensing Storage temperature: -40°C~70°C Storage humidity: 5%~90%RH non-condensing |
| Dustproof and waterproof grade | IP65 |
| packing list | Outdoor waterproof 4G router: 1 set of screw hole positioning stickers: 1 piece of plastic expansion tube/self-tapping screw: 2 each self-tapping screw (fixed inner shell): 1 quick installation guide: 1 |
