TP-LINK TL-TR960G 4G Wireless Router
Protocol standard
IEEE802.11a
IEEE802.11b
IEEE802.11g
IEEE802.11n
IEEE802.11ac
IEEE802.3
IEEE802.3u
IEEE802.3ab
2.4GHz frequency band: 300Mbps
5GHz frequency band: 867Mbps
4G:LTE-TDD,LTE-FDD
3G:WCDMA
2G:GSM
LTE-TDD BAND 34/38/39/40/41
LTE-FDD BAND 1/3/5/8
UTMS(WCDMA) BAND 1/8
GSM 900/1800MHz
3 10/100/1000M adaptive WAN/LAN ports, support automatic flip (Auto MDI/MDIX)
reset button
easy to-exhibition button
SYS system instructions
Each port link / ACT indicator
Bare size
Technical Specifications
| Property Description | Property Value |
|---|---|
| Protocol standard | IEEE802.11a IEEE802.11b IEEE802.11g IEEE802.11n IEEE802.11ac IEEE802.3 IEEE802.3u IEEE802.3ab |
| Wireless rate | 2.4GHz frequency band: 300Mbps 5GHz frequency band: 867Mbps |
| Network Type | 4G:LTE-TDD,LTE-FDD 3G:WCDMA 2G:GSM |
| Frequency Range | LTE-TDD BAND 34/38/39/40/41 LTE-FDD BAND 1/3/5/8 UTMS(WCDMA) BAND 1/8 GSM 900/1800MHz |
| interface | 3 10/100/1000M adaptive WAN/LAN ports, support automatic flip (Auto MDI/MDIX) |
| Button | reset button easy to-exhibition button |
| LED | SYS system instructions Each port link / ACT indicator |
| size and weight | Bare size (LxWxH): 113*113*95mm Package size (LxWxH): 171*152.5*152.5mm < p>Bare machine weight: 0.32kg (single machine, without accessories and packaging)Whole machine weight: 0.58kg (single machine, including accessories and packaging) |
| network status | Wireless settings Guest network settings Mobile network/WAN port network status LAN port network status |
| Equipment management | device information Real-time network speed speed limit Internet time management Disable device |
| Application functions | Wireless Bridge Press Visitor Network Signal Adjustment IP and MAC Address Bind Administrator identity AP isolation Virtual server DMZ host DDNS |
| Advanced Features | TP-LINK ID information Internet settings Wireless settings traffic management LAN port settings< /p> software upgrade modify administrator password backup and load configuration reboot and factory reset system log |
| Packaging accessories | 4G Wireless Router TL-TR960G Power Adapter User Manual Warranty Card |
| Use environment | operating temperature: 0° C to 40° C storage temperature: -40° C to 70° C Working humidity: 10% to 90% RH does not condense storage humidity: 5% to 90% RH does not condense |
