TP-LINK TL-XDR6020 Easy Exhibition Edition AX6000 Dual Band Gigabit Wi-Fi 6 Wireless Router
Wi-Fi
IEEE 802.11a/b/g/n/ac/ax wireless protocol
maximum radio rate 5952Mbps (2.4GHz 1148Mbps, 5GHz 4804Mbps)
beamforming ( Beamforming)
4 x 4 MU-MIMO
WMM: Based on priority data processing and forwarding
Wi-Fi multi-frequency one
Easy Exhibition Function
4 10/100/1000Mbps rate adaptive Ethernet interface, support WAN / LAN adaptive (network port blind plug)
Naked Machine Size (length x width x height): 285 x 202 x 210mm,
packaging size (length x width x height): 502.5 * 323.5 * 78.5mm
Naked Machine Weight: 0.48kg (single, excluding accessories, packaging)
machine weight: 1.46kg (single, including accessories, packaging)
Technical Specifications
| Property Description | Property Value |
|---|---|
| Wi-Fi | IEEE 802.11a/b/g/n/ac/ax wireless protocol maximum radio rate 5952Mbps (2.4GHz 1148Mbps, 5GHz 4804Mbps) beamforming ( Beamforming) 4 x 4 MU-MIMO WMM: Based on priority data processing and forwarding Wi-Fi multi-frequency one Easy Exhibition Function |
| Ethernet port | 4 10/100/1000Mbps rate adaptive Ethernet interface, support WAN / LAN adaptive (network port blind plug) |
| size and weight | Naked Machine Size (length x width x height): 285 x 202 x 210mm, packaging size (length x width x height): 502.5 * 323.5 * 78.5mm Naked Machine Weight: 0.48kg (single, excluding accessories, packaging) machine weight: 1.46kg (single, including accessories, packaging) |
| Antenna type | External Whole Outer Outer Outer: 4 2.4G Antenna, 4 5G Antenna |
| Software function | Wireless Bridge P Signal Adjustment Terminal Manage IP and MAC Address Bind AP Isolated Virtual Server Dynamic domain name service (DDNS) DMZ host automatic cleaning wireless timing switch Local Online / Local Firmware / Remote Upgrade |
| management | Computer / Mobile / PAD Web Management Mobile App Management |
| Safety | WPA-PSK, WPA2-PSK, WPA3 wireless encryption host network, guest network administrator identity limited |
| power supply | DC power supply, factory delivery 12V/2A power adapter |
| packing list | 1 router 1 power adapter 1 network cable (1 m) 1 quick installation guide 1 parameter record label |
